Designing a database interface with postgres schemas

  3 min 7 s   Programming

I’m currently working on a project — a highly customizable logbook with analytics tools — and part of the design process was defining the communication between my app and the database.

I wanted to apply some ideas I’ve been cooking for a while and that I don’t see very often in the industry, that is using schemas for separation of concerns and functions for the contracts. This setup provides a clear interface while omitting implementation details, which is what we do in everything else, right?

Disclaimer: This concept is nothing new and PostgREST offers a similar solution.

First, I created my schemas, the app_user role, and set the permissions. My current setup has four custom schemas, each with a specific responsibility:

BEGIN;

-- Create the four core schemas
CREATE SCHEMA IF NOT EXISTS core;
CREATE SCHEMA IF NOT EXISTS api;
CREATE SCHEMA IF NOT EXISTS internal;
CREATE SCHEMA IF NOT EXISTS checks;

-- Replace 'supersecurepassword' with your real secret
CREATE ROLE app_user LOGIN PASSWORD 'supersecurepassword';

-- Revoke ALL access from PUBLIC (i.e., all users) on all custom schemas
REVOKE ALL ON SCHEMA core, api, internal, checks FROM PUBLIC;

-- Revoke all privileges on tables and functions (applies to existing objects)
REVOKE ALL ON ALL TABLES IN SCHEMA core, internal, api, checks FROM PUBLIC;
REVOKE ALL ON ALL FUNCTIONS IN SCHEMA core, internal, api, checks FROM PUBLIC;

---------------------------------------------------------------------------------
GRANT USAGE ON SCHEMA api TO app_user;

-- One-off grants for existing objects
GRANT SELECT
  ON ALL TABLES IN SCHEMA api
  TO app_user;

GRANT EXECUTE
  ON ALL FUNCTIONS IN SCHEMA api
  TO app_user;

-- Default privileges for future objects
-- Obs: you should have a user with privileges such as api_owner for this.
ALTER DEFAULT PRIVILEGES FOR ROLE api_owner
  IN SCHEMA api
  GRANT SELECT ON TABLES TO app_user;

ALTER DEFAULT PRIVILEGES FOR ROLE api_owner
  IN SCHEMA api
  GRANT EXECUTE ON FUNCTIONS TO app_user;

COMMIT;

With this setup, I then proceeded to create internal functions like a snowflake_id generator, and the tables for the system.

BEGIN;

-- I'm omitting the def of generate_snowflake_id
-- and workout table for the sake of brevity
CREATE TABLE core.exercise (
    exercise_id BIGINT DEFAULT internal.generate_snowflake_id() PRIMARY KEY,
	workout_id BIGINT NOT NULL REFERENCES core.workout(workout_id) ON DELETE CASCADE,
    exercise_name VARCHAR(100) NOT NULL
);

COMMIT;

You could add the schema names to the global search_path, but I prefer to fully qualify them; it makes it easier to identify which schema each component belongs to.

For the API, I created functions for the operations I needed on a given resource.

BEGIN;

-- API/CREATE_EXERCISE
CREATE OR REPLACE FUNCTION api.create_exercise(
  p_workout_id     BIGINT,
  p_exercise_name  TEXT
)
RETURNS BIGINT
LANGUAGE sql
SECURITY DEFINER
VOLATILE
SET search_path = api, core, pg_temp
AS $$
  INSERT INTO core.exercise (workout_id, exercise_name)
  VALUES (p_workout_id, p_exercise_name)
  RETURNING exercise_id;
$$;

-- API/GET_EXERCISE_LIST
CREATE OR REPLACE FUNCTION api.get_exercise_list(
  p_workout_id BIGINT
)
RETURNS TABLE (
  exercise_id   BIGINT,
  exercise_name TEXT
)
LANGUAGE sql
SECURITY DEFINER
STABLE
SET search_path = api, core, pg_temp
AS $$
  SELECT exercise_id, exercise_name
  FROM core.exercise
  WHERE workout_id = p_workout_id;
$$;

COMMIT;

And that’s it! Now I have a clean interface that my application can consume from, which doesn’t leak any implementation details, improves code versioning, facilitates changes to business rules in real time, and has a safer environment for production.

Important notes:
